Drew

CAD Booster B.V.

Create 2D drawings twice as fast. Store your drawing preferences for each client in blueprints and start a new drawing from a blueprint in one click. Drew adds views, tables, dimensions and makes everything fit after every change. Works great for weldment and sheet metal drawings.

parter_logo

Drew is the only SOLIDWORKS add-in that automates creating drawings from scratch. We prefer settings over popups, so we store a lot of your drawings preferences in what we call 'blueprints'. You can create a blueprint for every customer that supplied their own templates or create a blueprint for each of your company's workflows. Once you defined at least one blueprint, we can do our one-click magic. Starting a new drawing only takes one click. Adding or removing a projected view takes one click, adding a sheet per unique body takes one. The list goes on.

Features

  • Store your drawing preferences in 'blueprints', then start a new drawing from a blueprint in one click. Or start 10 drawings at once.

  • It takes a single click to make changes: add or remove a view, add a block or add dimensions.

  • After each change, AutoFit determines the best sheet sale and view positions and fits all views, tables and blocks onto the available space.

  • Drew uses your preferred drawing template and sheet format to start a drawing, then adds views, tables and outer dimensions.

  • Create a sheet per unique body in one click. Each body gets your preferred views, dimensions and blocks. A weldment body gets angle dimensions, a sheet metal body gets a flat pattern.

Benefits

  • Create 2D drawings twice as fast. Drew does magic for weldments and sheet metal parts.

  • Create more consistent drawings by storing your preferences in blueprints. Share your settings with a colleague in seconds.

  • You can choose between floating and node-locked licenses. All licenses include unlimited access to all features and include support and updates. We release an update every 1-2 months.

  • Never forget to make a drawing of a part or a body because you can easily verify that you're done.

  • Drew does not require any changes in your modeling techniques, it works with any model and with existing templates. Even the resulting drawing does not use any custom features, so everyone can edit the drawings.

Resources

Video

Double your drawing speed

Drew starts a SOLIDWORKS drawing in one click and creates a sheet for each body in seconds. Drew makes creating drawings fun again.

Watch Video
partner_logo
OUR PARTNER

CAD Booster B.V.

CAD Booster automates the boring bits of engineering. We love streamlining complex workflows into one-click magic. Create 2D drawings twice as fast with Drew. Stop scrolling through endless lists of fasteners with Lightning.
